Description of external components
Fig. A
1 Steam valve Caution: This component can become extremely hot and cause burns
2 Hot water valve Caution: This component can become extremely hot and cause burns
3 Pressure gauge boiler
4 Cups tray Caution: Can become very hot.
5 Tank level control ( red lamp )
6 “Machine on” ( green lamp )
7 On / Off switch
8 Group, coffee brewing head. Caution: This component can become extremely hot and cause burns
9 Filter holder. Caution: This component can become extremely hot and cause burns
10 Drip tray
