Gintec G20M - Technical Parameters

1
7 Technical Parameters
GNSS
Channel 432
Satellites
GPS: L1,L2,L5
GLONASS: L1,L2
BDS: B1,B2,B3
Galileo: E1,E5A,E5B
QZSS: L1,L2,L5
SBAS: L1
Cold start ＜40s
Signal recapture ＜1s
Accuracy
Static Accuracy
Horizontal:
±
(2.5+1×10-6D)mm
Vertical:
±
(5.0+1×10-6D)mm
DGPS Accuracy Horizontal: 0.4m; Vertical: 0.8m
RTK Accuracy
Horizontal: ±(10+1×10-6D)mm
Vertical: ±(15+1×10-6D)mm
Time Accuracy 20ns
Tilt
Measurement
Accuracy(within
30
°
)
＜2cm
Update
Frequency
5Hz
POWER
Battery Built-in Battery,9600mAh 3.7V
Duration ≥9h
Input 5V/2A DC
SYSTEM
Operation
System
Linux
Memory 32G Internal
Bluetooth V2.1+EDR / V4.0 Dual Mode
WIFI 802.11 a/b/g/n/ac
4G Network
LTE FDD: B1/B3/B5/B8
LTE TDD: B38/B39/B40/B41
TD-SCDMA: B34/B39
CDMA: BC0
WCDMA: B1/B8
GSM: 900/1800MHz
Tilt Survey
Support Integrated with new calibration free
tilt module
