7.3 Mounting the rockers
￭ Slide the side of the rocker into place (see figure 6).
Figure6: Slide the side of the rocker into place
￭ Press in the middle of the rocker (see figure 7).
Figure7: Press lightly in the middle of the rocker
The rocker snaps into place.
Device is ready for operation.
In order to optimise the gap dimensions between the rockers and the cover
frame, the rockers can be moved slightly after snapping into place.
