GIWEE R32 - Specifications; Model, Piping, and Wiring Specifications

4
2Specifications
2.1 Model Reference
Refer to the following table to determine the specific indoor and outdoor unit model number of your
purchased equipment.
Indoor unit model
Outdoor unit model
Capacity (Btu/h)
Power supply
CCG-V09HR4-GSA-S40
COU-D09HR4-AA01-S40
9K
220~240V, 50Hz,
1Ph
CCG-V12HR4-GSB-S40
COU-D12HR4-AA01-S40
12K
CCG-D18HR4-GSC-S40
COU-D18HR4-A01-S40
18K
CCG-D24HR4-GSC-S40
COU-D24HR4-C01-S40
24K
2.2 Pipe length and drop height
The length of refrigerant piping will affect the performance and energy efficiency of the unit.
Nominal efficiency is tested on units with a pipe length of 5 meters (16.5ft). A minimum pipe run of
3 meters is required to minimize vibration & excessive noise.
Refer to the table below for specifications on the maximum length and drop height of piping.
Capacity
(Btu/h)
Liquid/gas side
pipe
Standard
length
Max. pipe
length
Max. high
drop
Additional
refrigerant
9K
Φ6.35/Φ9.52
5m
25m
10m
R32, 15g/m
12K
Φ6.35/Φ9.52
5m
25m
10m
R32, 15g/m
18K
Φ6.35/Φ12.7
5m
30m
20m
R32, 15g/m
24K
Φ6.35/Φ12.7
5m
30m
20m
R32, 15g/m
Note: Oil trap should be set every 10m of vertical distance.
2.3 Electrical wiring diagrams
