Glatz CASTELLO Pro - English

2322
Table of Contents
Welcome 23
Optional accessories 23
Technical data 23
Safety information 24
Assembly and commissioning 26
Appliance Overview 28
Opening / closing the parasol 28
Control of light and heating 29
Change of battery on the remote 29
What do you have to do if… 30
Handling and maintenance 30
Disassembly 30
Warranty 31
EC Conformity declaration 31
Disposal 31
Welcome
Congratulations on the purchase of your new Castello Pro. You have pur-
chased a high quality parasol. These instructions forms part of this product.
It contains important safety, usage and disposal information for users of the
product. Please familiarise yourself with all the information listed before using
the product. The product may only be used as described herein and for the
use scenarios stated. If you continue to use it and care for it properly, your
Castello Pro parasol will serve you well for many years to come.
Warning words used
!DANGEROUS Immediately dangerous situation which can result in death or
severe injuries.
!CAUTION Potentially dangerous situation which can result in minor or
moderate injuries.
!NOTICE A situation that can lead to property damage.
The product serves as a device for the protection of the human body from solar
radiation. The product may only be used in private households, in the catering and
hotel sector or in a comparable environment. The product may only be used in
accordance with these installation and operating instructions. Any use other than
the uses described in these installation and operating instructions shall be consid
-
ered improper use. We reserve the right to make modications due to technical
advances. In these instructions the CASTELLO Pro may also be referred to as ‘the
product’ or ‘parasol’.
Intended use
Optional accessories
A high quality range of accessories is included with your parasol: It includes,
among other things, the following products, which go perfectly with your
parasol:
• Base • Rain gutters
• Mounting plate • Securing systems
• Ground Socket • Wind shield
• Protective cover • Impact protection
Consult your GLATZ dealer about this.
Technical data
Electrical connection for parasol Remote control
LED 230 V, 13 A, L+N+PE, 50 Hz, <0.2 kW
LED + heating 400 V, 16 A, 3L+N+PE, 50 Hz, <6.2 kW
Heating 400 V, 16 A, 3L+N+PE, 50 Hz, <6.0 kW
IP protection class IP68
Battery CR 2430
Size
[cm]
Base area
[m
2
]
Closing height
[cm]
Passage height
[cm]
Overall height
[cm]
ø 350
ø 400
ø 450
ø 500
ø 550
ø 600
350 x 300
400 x 300
450 x 350
500 x 400
550 x 450
300 x 300
350 x 350
400 x 400
450 x 450
500 x 500
8.7
11.3
14.3
17.7
21.4
25.5
10.5
12.0
15.8
20.0
24.8
9.0
12.3
16.0
20.3
25.0
162
154
146
137
129
120
120
106
94
81
81
127
114
100
85
81
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
341
360
377
394
412
429
353
360
384
407
443
342
365
387
412
440
Colour temperature (built-in lighting) 3000 K
Maximum brightness (built-in lighting) 2500 to 4000 lumen, depending on the size
