www.glendimplex.de 452167.66.02 · FD 9509 EN-10
English
LSA 60TUR
12 Device information
1 Type and order code
LSA 60TUR
2Design
Heat source Air & brine
2.1 Model Reversible with mode for two heat sources
2.2 Controller WPM wall-mounted
2.3 Thermal energy metering no
2.4 Installation location Outdoors
2.5 Performance level 2
3 Operating limits
3.1 Heating water flow / return °C
up to 60
1
±2 / from 18
Cooling water flow °C
+6
2
to +20
Air (heating) °C -20 to +40
Air (cooling) °C +15 to +45
Brine (heating) °C
+5
flow
to +25
return
4 Flow / sound
4.1 Heating water flow rate / internal pressure differential
in accordance with 14511 A7/W35-30 m³/h / Pa 10.5 / 6500
A7/W45-40 m³/h / Pa 10.2 / 6200
A7/W55-47 m³/h / Pa 6.2 / 2300
minimum m³/h / Pa 5.3 / 1700
4.2 Minimum cooling water throughput /internal pressure differential
3
m³/h / Pa
10.8 / 6900
4.3 Brine flow rate / internal pressure differential m³/h / Pa 11.0 / 32500
4.4 Sound power level according to EN 12102Normal mode / lowered operationdB(A) up to 74 / up to 70
4.5 Sound pressure level at a distance of 10 m (air outlet side)
4
Normal operation / reduced operation dB(A)
up to 45 / up to 41
4.6 Air flow (controlling range EC fan) m³/h 10000 - 22000
5 Dimensions, weight and filling quantities
5.1 Device dimensions
5
H x W x L mm
2300 x 2110 x 1000
5.2 Weight of the transportable unit(s) incl. packaging kg 1090
5.3 Device connections for heating inches R 2"
5.4 Device connections for brine inches R 2"
5.5 Refrigerant / total filling weight type / kg R417A / 33.0
5.6 Lubricant / total filling quantity type / litres Polyolester (POE)/7.2
5.7 Volume of heating (cooling) water in device water / brinelitres 18.8 / 12.0
6 Electrical connection
6.1 Supply voltage / fuse protection 3~/PE 400V (50Hz) / C50A
6.2 Control voltage / fusing via WPM 1~/N/PE 230V (50Hz) / 4 ET
6.3 FI circuit breaker / category Yes / A
6.4 Degree of protection according to EN 60 529 IP 24
6.5 Starting current limiter Soft starter
6.6 Rotary field monitoring No
6.7 Starting current A 78
6.8 Nominal power consumption A7/W35 / max. consumption
6
kW
14.75 / 29.9
6.9 Nominal current A7/W35 / cos A / --- 28.8 / 0.8
6.10 Power consumption of compressor protection (per compressor) W 70, thermostatically controlled
6.11 Power consumption of fan kW up to 3.1
7 Complies with the European safety regulations
7
8 Additional model features
8.1 Type of defrosting Reverse circulation
8.2 Condensate tray frost protection / Water in device is protected from freezing
8
Ja
8.3 max. operating overpressure (heat source / heat sink) bar 3.0
8.4 Hydraulic 4-way reversing valve (external)
2
Accessories (recommended)
