MAINTENANCE JUNO-NET
Connecting A PS2 PC Keyboard To The Main Panel
DISPLAY
LOOPCARD
HEADER
LOOPCARD HEADER
MASTER
RESET
PRINTER
CONNECTOR
PRINTER
FUSE
PS2 PC KEYBOARD
ADAPTOR
STANDOFFS (4) FOR LOOPCARD
SIM CARD CONNECTOR
QUAD UART
50 WAY BOX HEADER FOR
J-NET-CON
16 WAY BOX HEADER FOR
LOOP CONNECTOR
LOOPCARD HEADER
JUNO-NET MOTHERBOARD (BACK VIEW)
J-NET-QUART:
QUAD UART
24
OPERATION & MAINTENANCE MANUAL
REVISION 0.7a
16-04-2004
