Glow-worm 24ci User Manual

11
4000123942-2
1 Technical Data
Heat input (max) NET Q 26,94 kW
91,200 BTU/H
Heat input (min) NET Q 9,91 kW
33,820 BTU/H
Heat output (max) NET P 23,6 kW
81,550 BTU/H
Heat output (min) NET P 8,9 kW
30,370 BTU/H
Efficiency - Sedbuk D 78,3%
Maximum heating temperature 87° C
Expansion vessel effective capacity 5 litres
Expansion vessel charge pressure 0,5 bar
Maximum system capacity at 75°C 110 litres
Safety valve, maximum service pressure 3 bar
Heating
Heat input (max) NET Q 26,94 kW
91,200 BTU/H
Heat input (min) NET Q 9,91 kW
33,820 BTU/H
Heat output (max) NET P 23,6 kW
81,550 BTU/H
Heat output (min) NET P 8,9 kW
30,370 BTU/H
Maximum hot water temperature 60 °C
Minimum hot water temperature 38 °C
Specific flow rate (for 35°C temp rise) 9,8 litres/min.
Threshold flow rate 1,7 litres/min.
Maximum supply pressure 10 bar
Minimum supply pressure 0,5 bar
Hot water
Electrical supply 230 V ~ 50Hz
Electrical rating 122 W fused at 3A
Level of protection IPX4D
Fuse rating 125mA
Electrical
Products outlet diameter 60 mm
Fresh air inlet diameter 100 mm
Combustion products values CO (60 ppm)
CO2 (6,7%)
NOx (48ppm)
Combustion
Ø Burner injector 1,2 mm
Inlet pressure 20 mbar
Maxi. Burner pressure 12,2 mbar
Mini. Burner pressure 2,25 mbar
Gas rate maximum 2,74 m
3
/h
Gas rate minimum 1,16 m
3
/h
Natural Gas (G20)
Ø Burner injector 0,73 mm
Inlet pressure 29 mbar
Maxi. Burner pressure 23,2 mbar
Mini. Burner pressure 4,41 mbar
Gas rate maximum 2,01 kg/h
Gas rate minimum 0,87 kg/h
Butane Gas (G30)
Ø Burner injector 0,73 mm
Inlet pressure 37 mbar
Maxi. Burner pressure 29,8 mbar
Mini. Burner pressure 5,4 mbar
Gas rate maximum 2,01 kg/h
Gas rate minimum 0,83 kg/h
Propane Gas (G31)
Heat input (max) NET Q 20,7 kW
70,628 BTU/H
Heat input (min) NET Q 11 kW
37,532 BTU/H
Heat output (max) GROSS P 18,4 kW
62,780 BTU/H
Heat output (min) GROSS P 8,9 kW
30,366 BTU/H
Efficiency - Sedbuk D 78,3%
Maximum heating temperature 87° C
Expansion vessel effective capacity 5 litres
Expansion vessel charge pressure 0,5 bar
Maximum system capacity at 75°C 110 litres
Safety valve, maximum service pressure 3 bar
Ø Burner injector 1,2 mm
Inlet pressure 20 mbar
Maxi. Burner pressure 8 mbar
Mini. Burner pressure 2,25 mbar
Gas rate maximum 2,2 m
3
/h
Heating
Electrical supply 230 V ~ 50Hz
Electrical rating 122 W fused at 3A
Level of protection IPX4D
Fuse rating 1,25mA
Natural Gas (G20)
Electrical
Products outlet diameter 60 mm
Fresh air inlet diameter 100 mm
Combustion products values CO (25 ppm)
CO2 (5,5%)
NOx (48ppm)
Combustion
Ø Burner injector 0,73 mm
Inlet pressure 29 mbar
Maxi. Burner pressure 14,8 mbar
Mini. Burner pressure 4,41 mbar
Gas rate maximum 1,63 kg/h
Gas rate minimum 0,87 kg/h
Butane Gas (G30)
Ø Burner injector 0,73 mm
Inlet pressure 37 mbar
Maxi. Burner pressure 19,2 mbar
Mini. Burner pressure 5,4 mbar
Gas rate maximum 1,61 kg/h
Gas rate minimum 0,83 kg/h
Propane Gas (G31)
24ci
18si
