Title GM Ultium EV Charging Station
User Manual
03MAR21 First Re l
21
8. TECHNICAL DATA
Model number 3004
Charging method AC Level 2
Vehicle connector Type 1
Mains connector NEMA 14–50
Number of phases Split single phase
Charging voltage 120 / 208 V, 120 / 240 V
Charging current 40/48 A
Rated frequency, fn 50-60 Hz
Charging power 9.6 kW / 11.5 kW
Humidity 0-95%
Max. Altitude 11483 ft. (3500 m)
Cooling Heat sink, natural convection
Energy meter Yes, internal
Positioning Fixing plate, wall mount
Enclosure dimensions 6 x 9.8 x17.2 inches (152.4 x 249 x 436.9 mm)
Enclosure material Plastic, metal
Enclosure color White/Black
Degree of protection Rainproof, Type 3R
Charge cable length 25 ft. (7.5 m)
Mains cable length 1 ft. (0.3 m)
Net weight (unit with cables) Approximately 24 lbs (10.9kg)
Net weight (holster) Approximately 1.7 lbs (0.8kg)
Packaging weight Approximately 35 lbs (15.9kg)
Packaging size (LxWxH) 30.7 x 13.8 x 7.3 inches (780 x 350.5 x 185.4 mm)
User interface LED interface
Connectivity Bluetooth® wireless technology, Wi-Fi
Communication protocol OCPP 1.6
App support
Smart device display, Manufacturer App for Android and iOS (OS Versions TBD)
Ambient operation temperature
and storage temperature
-22°F to +122°F (-30°C to +50°C)
9. OVERCURRENT AND SHORT-CIRCUIT
PROTECTION
Rated current, In 40/48 A
Ground fault detection Integrated, no additional required (CCID20)
RCD Manual Reset
