Title GM Ultium EV Charging Station
User Manual
03MAR21 First Re l
SAR
PART No.
SHEET
AH
5
2.3 INCLUDED IN THE BOX
1. GM Ultium EV Charging Station
1
2. Cable Wall Mount
3. User Manual/Safety Manual/Drilling template
4. Multi-Bit Screwdriver
5. 2 Screwdriver Bits
6. 8 Screws
7. Blind Plug
2.4 INCLUDED IN THE ACCESSORY BOX
7654
32
2.5 EQUIPMENT OVERVIEW
4
3
2
1
1. GM Ultium EV Charging Station with indicator
panel
2. NEMA 14–50 Plug
3. EV Type-1 Connector
4. Charging Station Wall Mount
