GMDE Powervortex4600TL - 3. Installation; 3.1 Operation Sequence

Global Mainstream Dynamic Energy Technology Ltd.
- 13 -
User Manual
Powervortex 5200TL hybrid inverter
OUTPUT GRID
Rated Output Voltage Ur [Vac]
1N~ 230
1N~ 230
Operating Voltage Adjustable Range Un
[Vac]
180-264
180-264
Rated Output Frequency FNETZ [Hz]
50
50
Rated Output Power PE [W]
4400
5000
Max. Output Power PEmax [W]
4400
5000
Max. Apparent power SEmax [VA]
4400
5000
Rated Output Current Ir [A]
19.1
21.7
Max. Output Current Imax [A]
21.0
23.8
Power Factor cosφ [λ]
[-0.8,+0.8] adjustable
[-0.8,+0.8] adjustable
Standby Power Consumption [W]
< 15
< 15
Night Power Consumption [W]
< 0.5
< 0.5
THD [V / I] (100% full power)
< 3%
< 3%
Acoustic Noise [dB]
< 55
< 55
Overvoltage Category (OVC)
OVC III
OVC III
SYSTEM
Type of inverter
Transformerless
Transformerless
MPPT tracking
2 Strings
2 Strings
Protective Class
I
I
Enclosure Protection (IP)
IP20(Indoor)
IP20(Indoor)
Operating Temperature Range [ºC]
-10 to 60 (> 45
Derating)
-10 to 60 (> 45 Derating)
Pollution degree (PD)
PD 3
PD 3
Altitude [m]
2000
2000
Weight [kg]
<25
<25
Size [mm]
550*610*192
550*610*192
Table 1 Inverter Specifications
3. Installation
3.1 Operation Sequence
Important Note before Operation
In order to ensure the smooth operation of hybrid inverter and reduce the negative impact on
local load in case of inverter maintenance, we strongly recommend the users to connect the
hybrid inverter into the existing electrical system as following figure shows:
