User Manual
Powervortex 5200TL hybrid inverter
Table 7 LCD display definition
4.1.4 LCD Display Menu Definition
The LCD menu includes display and setting menus. The display menu shows system parameters
and their values. The setting menu is to configure the values ofparameters to ensure the system
is running according to customer requirements.
Users can change flip bypressing “▲”, “▼”button to check information on the display menu. To
enter the setting menu, long pressing the“OK”button for 3 seconds. Choose parameters to be
set by pressing“▲”, “▼” buttons.
Parameter list and definition on display menu:
Item list
Display content
PV1
Voltage
Current
PV2
Voltage
Current
BAT
Voltage
Current
AC
GRID voltage(on-grid)
GRID voltage(on-grid)
EMERGENCY LOAD voltage(off-grid)
EMERGENCY LOAD current(off-grid)
TEM
PV side temperature
Battery DCDC side temperature
FRE
Grid frequency
ET1
Daily PV production
SOC
Battery capacity
SWC
software version No. of Powervortex 4600TL / 5200TLcommunication conversion
board
SWM
CPU software version No. of Powervortex 4600TL / 5200TL DPS1
SWS
CPU software version No. of Powervortex 4600TL / 5200TL DPS2
SWB
CPU software version No. of Powervortex 4600TL / 5200TL DPS3
Table 8 LCD display menu content
4.1.5 LCD Setting Menu
Setting the device when initial commissioning.
4
PV1 Power
Power of PV1
5
PV2 Power
Power of PV1
6
Grid power
Power out/into the grid
7
Load power
The current load power
8
Battery power
Battery charging / discharging power
9
Menu
Menu and data display
Item
Description
PW
Password 6666 or 1111
TIM
Time
TYP
Battery type
00
Lithium-ion battery(default)
01
Lead battery
