GME Electrophone TX3400 - Introduction; Features Overview

2
CONTENTS
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Introduction
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Operation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Selective Calling
. . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Using the Quiet Mode
. . . . . . . . . . . . . . . . . . . . . 12
Group Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Page Mode
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
CTCSS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
CTCSS Tone Frequency Chart
. . . . . . . . . . . . 17
Disabling Functions . . . . . . . . . . . . . . . . . . . . . . . 18
Installation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Repeaters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Channel Frequency Chart
. . . . . . . . . . . . . . . . . 22
Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Your GME Electrophone TX3400 transceiver is
Australian designed and built and is the most
advanced UHF Citizen Band radio available.
The TX3400 combines the very latest in
electronic hardware with the most up-to-date
computer aided design and manufacturing
techniques to produce an extremely compact
mobile radio with outstanding specifications
and performance.
The TX3400's small size means it can be
mounted in almost any convenient location and
its strong diecast aluminium chassis makes it
the most robust transceiver of its kind. With
just two rotary controls and four touch keys,
the TX3400 is easy to operate.
FEATURES
• Microprocessor Controlled Frequency
Synthesiser: Allows user programmable
control of scanning, channel memories and
selected feature options.
• Permanent Memory: Retains all user
settings in non-volatile memory even when
the power has been removed.
• Programmable Scan Function: Scans up
to 40 user programmable channels with
both Group and Open scan functions
available.
• Remote or Local Installation Option: The
TX3400 can be mounted either remotely
using the separate control head, or locally
with the control head attached to the main
unit.
INTRODUCTION
The following items are included with your TX3400
If any items are missing or damaged, please contact your dealer or place of purchase.
• TX3400 Transceiver with Remote Head Unit
• Microphone
• Microphone Clip
• Instruction Manual
• Mounting Cradle for Main Unit
• Mounting Bracket for Remote Unit
• Screw Pack
• DC Lead
