Page 2 Instruction Manual TX7200
The TX7200 is a radio transmitting device.
• When transmitting, keep the antenna more than 25 mm from any part of the head or body.
• Do not transmit near electrical blasting equipment or in explosive atmospheres.
• Do not allow children to operate a radio transmitter unsupervised.
WARNING: SAFETY INFORMATION
CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . 3
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . 3
Removing the Battery Pack ...............4
Refitting the Battery Pack ................4
Charging the Battery Pack . . . . . . . . . . . . . . . 4
BASIC OPERATION . . . . . . . . . . . . . . . . . . . . . . . . 4
Turning the TX7200 on or off .............4
Adjusting the receiver volume . . . . . . . . . . . . 4
Controls and Functions . . . . . . . . . . . . . . . . . 4
Selecting Channels .....................4
Alphanumeric labels. . . . . . . . . . . . . . . . . . . . 4
Activating the Backlighting . . . . . . . . . . . . . . 4
Transmitting ..........................5
Receiving . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PROGRAMMABLE FUNCTIONS . . . . . . . . . . . . . . . 5
MAINTAINING YOUR BATTERY PACK ...........6
Low Battery Indicators ..................6
Battery Charging . . . . . . . . . . . . . . . . . . . . . . 6
Cycling your battery pack ................6
Battery Usage . . . . . . . . . . . . . . . . . . . . . . . . 6
SPECIFICATIONS ..........................7
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
After Sales Service .....................8
INTRODUCTION
The TX7200 is a rugged, easy to operate, full featured
commercial hand-held transceiver operating in the
450–520 MHz UHF band. The TX7200 assembly is a very
strong structure with a single diecast frame housed in a
polycarbonate alloy case.
The range of a UHF FM signal is usually considered 'line-of-
sight'. Generally the range of your TX7200 radio will vary
according to your location and the height of your antenna.
UHF signals are easily blocked by hills or large buildings
so you won’t get as much range in a valley or built-up city
areas as you will from a hilltop or in open country. If you are
having trouble contacting someone, try moving to an open
space or a higher location. Typical portable range is around
3 to 5 km depending on the terrain. Moving to a higher
location or using a repeater could extend its range.
