GMI D1033D User Manual

Technology for safety
7
D1000 series - Intrinsically Safe Isolators
Terminal blocks connection data
Stripping
lenght
Grey terminal blocks
on Safe Area
Screwdriver
for Trimmers
4 x 1 mm
7 mm
Connection data
Conductor cross section solid From 0.2 mm² to 2.5 mm²
Conductor cross section stranded From 0.2 mm² to 2.5 mm²
Conductor cross section stranded, with ferrule without plastic sleeve From 0.25 mm² to 2.5 mm²
Conductor cross section stranded, with ferrule with plastic sleeve From 0.25 mm² to 2.5 mm²
Conductor cross section AWG From 24 to 12 AWG
Blue terminal blocks
On Hazardous Area
