DLV VALVE MANUAL
I NSTALLATION , U SE AND M AINTENANCE
3 INSTALLATION
ATTENZIONE
During the installation:nvere exclude safety devices and never power-on the motor pump.
3.1 HYDRAULIC CONNECTION SAMPLES
DLV A3 - 3010 – MR with cabinet up to 150 lt DLV A3 - 3010 – MR no cabinet from 180 to 210 lt
DLV A3 - 3010 - MRL MC with cabinet up to 150 lt DLV A3 - 3010 - MRL MC no cabinet 180/210 lt
