Part List - HSG Parts
COLOUR
TOP HSG ASM (C80R)
see note below
TOP HSG ASM (C70R)
see note below
GOLD 22121770 22121870
WARM GREY 22121771 22121871
ESPRESSO 22121772 22121872
DEEP BLACK 22121773 22121873
BRONZE 22121774 22121874
CHAMPAGNE 22121775 22121875
SPARKLING SILVER 22121776 22121876
GRAPHITE 22121777 22121877
TOP HSG,TGL,PB & transp mic lters
All HSG parts are nano coated
Note C70R & C80R:
If the TOP HSG is damaged, it can be replaced.
If the the mic lters need to be replaced, they can
be replaced without separating the HSG parts -
see instr in this doc
Note that the white mic lters are changed to
transp lters
TOP HSG,PB & transp mic lters
Note C70R:
The black mesh lters inside the TOP HSG are no
longer mounted. They are instead mounted onto
the module/frame
