GNS 3000 - Page 7

Logging Operation Mode
* Please verify the following:
1. Is the Storage-Card full or 󰈡 le-limit is reached => Delete non required 󰈡 les
2. Firmware update 󰈡 le “update.gns” is present while no external power
attached => Attach external power for FW update or delete “update.gns” 󰈡 le
* Please verify the following:
1. Is the Storage-Card FAT(32) formatted or larger than 32GB => Format
Storage-Card FAT(32) or use Storage-Card <=32GB
Orange logger
status
Green GPS
status
Double
fl ashing
On with short
interruptions
Flashing
alternately
Fast fl ashing
for 2 seconds
Logging active; no GPS
position available
Logging active; GPS
position available
Logging requested, but the Storage-Card is
full, the 󰈡 le limit is reached, or a 󰈡 le named
update.gns is present and there is no external
power attached*
-
Logging requested,
but no Storage-Card
present
-
-
Fast fl ashing >
2seconds
Logging requested,
but Storage-Card not
FAT(32) formatted,
exceeding 32GB
or otherwise not
suited for GNS3000
operation*
-
Combo LED (green / orange)
2
1
1
2
