Go Power GP-PWM-30 User Manual

Solar Controller
GP-PWM-30
______________________________________________________________________
10
© 2012 Carmanah Technologies Corporation
September 2012
6.0 Operating Instructions
Power Up
When the GP-PWM-30 is
connected to the battery, the
GP-PWM-30 will go into Power
Up mode.
Icons Displayed: Three
horizontal dashes
Setting the Battery Type / Charging Profile
Set the Battery Type / Charging
Profile by holding down the B
Button for 5 seconds. When the
display begins blinking you may
set the Battery Type by toggling
through the Charging Profile
numbers 1, 2 or 3 by pressing
the B Button.

Go Power GP-PWM-30 Specifications

General

Input Voltage	12 VDC
Max Input Current	30A
Efficiency	Up to 99%
Battery Types	AGM, Flooded, Lithium, Gel
Protection Features	Reverse Polarity, Short Circuit
