Goblin MINI COMET - Page 11

Motor
Assembly
Page 10
Chapter 5, Motor Assembly
Tail Belt Tensioner Assembly
Flanged Bearing
4x 7x2.5mm
(HC486-S)
Socket Head Cap
Screws M2.5x8mm
(HC020-S)
Tail Belt Ilder
Assembly
Carbon Rod Guide
[H0909]
Column Tail
Belt Tensioner
(H0872-S)
Flat Head Cap
Screws M2.5x5mm
(HC128-S)
Tail Belt Ilder
Tail Belt Ilder Assembly ...x2
FBL Support
(H0927-S)
Tail Belt Tensioner
Assembly
Socket Head Cap
Screws M2.5x8mm
(HC020-S)
Finishing
Washer M2.5
(H0255-S)
BAG 4.3
