Goblin MINI COMET - Page 9

10mm 10mm
Aprox 416mm
Page 8
Chapter 4, Tail System
Tail System
Assembly
Socket Head Cap
Screw M2x6mm
(HC004-S)
Socket Head Cap
Screw M2x6mm
(HC004-S)
Note: Please allow plenty of time for the glue to cure before inserting the plastic ball link onto the threaded rod.
Plastic Ball Link
(H0779-S)
Linkage M2x22mm
[H0561]
Carbon Rod
2x 3x376mm
(HC512-S)
Linkage M2x22mm
[H0561]
Plastic Ball Link
(H0779-S)
BAG 3
Tail Boom
Assembly
Tail Locking Element
(H0910-S)
Double
Sided Tape
[HA118]
