EZ100/EZ300/EZ500 Series
12
Pass the label stock through the printer as shown in the illustration on the right
Close the label dispenser and the print mechanism. The installation is completed now.
LABEL STOCK
THE PAPER FEED ROLLER OF PRINTER
THE PAPER FEED ROLLER OF LABEL
DISPENSER MODULE
LINER
LABEL
