7
2 Printer Setup
007
2. Then place the left-hand side of the ribbon.
Load The Ribbon On The Printer
For Ribbon Supply Module
1. Place the right-hand side of ribbon first.
Right side
Push the ribbon to tighten
the spring of the holder
Align the ribbon core
to the holder
SPRING OF HOLDER
Left side
Align the notch of the ribbon core to the spoke
NOTCH OF RIBBON CORE
SPOKE
RIBBON SUPPLY MODULE
