Godex RT200 - Page 41

37
5 Accessories
037
2. Feed the Label stock through the label guides.
3. Pull the label liner through the platen and the steel of the label dispenser.
****Labels should be at least 25 mm high.
Through the label guides
LABEL LINER
PLATEN
STEEL
Loading Label Roll With The Label Dispenser Module
1. Remove the first label from the label stock.
Tear a label
THE FIRST LABEL
LABEL STOCK
LABEL LINER
