DESCRIPTION AND SPECIFICATIONS
MAIN DETAILS
Phono Preamplifier with SKC and TFT colour display
Equalisation Curve control: 3 selectable curves [RIAA -
Decca-London - American-Columbia + enhanced]
Subsonic filter: 10Hz/36dB octave
Frequency response: 20Hz /20KHz [Enh. 20Hz/50KHz] @
+/-0.3dB
THD (Total Harmonic Distortion): <0.05%
Signal to noise ratio: -89dB
Dynamic response: 105dB
DIMENSIONS AND WEIGHT
Dimensions: 200mm W 80mm H 260mm D
Weight: 3Kg net. - 4Kg boxed
FINISHES
Brushed Aluminium available in Black, Silver or Gold
ANALOGUE INPUTS
MM/MC two independent stereo RCA
Input sensitivity: 0.1mV MC up to 7.0mV MM
Input impedance: 9 options [10Ω, 22Ω, 47Ω, 100Ω,
220Ω, 470Ω, 1000Ω, 22KΩ, 47KΩ]
Gain: 45/65dB (+6dB/-3dB)
ANALOGUE OUTPUTS
Line output level (fixed): stereo RCA @ 1V and balanced
XLR @4V
POWER
100-120V or 220-240V, 50/60Hz
Power consumption: 10W Super Linear supply
Standby consumption: < 0,5W
4
