FUNCTIONS AND DISPLAY
Load 47kΩ
100Hz 1kHz 10kHz
IN 1
Gain +3db
RIAA
MM
GN
Disp.
TYPE SELECTION
MM
MC
GAIN SELECTION
LOAD SELECTION
-3 dB
0 dB
+3 dB
+6 dB
10Ω 22Ω 47Ω 100Ω 220Ω
470Ω 1KΩ 22KΩ 47KΩ
DISP (DISPLAY OFF)
turns the display OFF, the display will turn ON again for a few
seconds when using the SKC KNOB
EXT (EXTERNAL)
external power supply PSU-
10 connected
INPUT SELECTION
IN 1
IN 2
Vinyl records were pressed by different labels: each and every one could
develop and use a different way to record and print records thus creating
different equalisation curves.
Aligning the curves of equalisation of reproduction to match the curves used
to produce the record is the best way to extract the correct audio signal from
the vinyl.
PH-10 offers a variety of the most commonly used curves, starting with the
standard RIAA, followed by the acclaimed original DECCA-LONDON and the
COLUMBIA-CBS AMERICAN.
Every curve is also offered in its ENHANCED version that can result in a crisper,
more vivid sound extracted from the vinyl and sometimes useful to achieve
even greater dynamic.
Selecting the curves is simple and intuitive using the SKC Knob design, making
PH-10 a great tool to discover again your records.
DISPLAY OVERVIEW
7
