Gold's Gym Cycle Trainer 310 - Step 2: Rear Stabilizer Installation; Step 3: Handlebar Post Adjustment; Step 4: Handlebar Attachment

6
2. Attach the Rear Stabilizer (8) to the Frame (1)
with two M8 x 35mm Carriage Bolts (52) and two
M8 Locknuts (62).
2
8
1
3
3. Orient the Handlebar Post (5) as shown.
Loosen the indicated Adjustment Knob (21) on
the front of the Frame (1) and pull it outward.
Then, insert the Handlebar Post (5) into the
Frame.
Move the Handlebar Post (5) upward or
downward to the desired position, release
the Adjustment Knob (21) into an adjustment
hole in the Handlebar Post, and then tighten
the Adjustment Knob. Make sure that the
Adjustment Knob is firmly engaged in an
adjustment hole.
5
Holes
1
4
4. Orient the Handlebar (6) as shown. Attach the
Handlebar to the Handlebar Post (5) with four
M8 x 15mm Button Bolts (54) and four M8
Locknuts (62).
52
62
21
6
5
62
54
