5
1. Orient the Front Stabilizer (7) as shown. Attach
the Front Stabilizer to the Frame (1) with two
M8 x 35mm Carriage Bolts (52) and two M8
Locknuts (62).
1
52
62
1
7
ASSEMBLY
• To hire an authorized service technician to assem-
ble the exercise bike, call 1-800-445-2480.
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you complete all assembly steps.
• In addition to the included tool(s), assembly
requires the following tools:
one Phillips screwdriver
one adjustable wrench
Assembly may be easier if you have a socket set
or a set of ratchet wrenches. To avoid damaging
parts, do not use power tools.
