Golden Eagle 3 Series - Replacement Parts List

REPLACEMENT PARTS LIST
REF. CURTIS
NO.
PART NO. DESCRIPTION
_____________________FIGURE 10_____________________________
1 D58530 Long Wireguard
2 A58291 E Ring
3 B58549 Handle/Linkage Ay. (see pg. 36 Fig. 11)
4 B85571-1 Formulation Tank Cap
5 D58552 Top Cover Ay. (See pg. 36 Fig. 11)
6 B85571-1 Fuel Tank Cap
Not Shown 85546 Cap Gasket
7 D58578 Carb. Cover/Rear Panel Ay.
D58577 Carb. Cover Ay.
D58529 Carb. Cover
G445351 J Spring
C58576 Rear Panel Ay.
A58584 Label, Fog/Spark Gap
A58520-2 Retainer, Black, Nylon
A58520-4 Stud, ¼ Turn, Ovalhead
A58520-3 Receptacle, ¼ Turn
B58586 Label, Starting Instructions
8 C58575 Side Panel
9 B58644 Formulation Injection Line Ay.
10 G114628 ¼ Tube Sleeve
11 G145463 ¼ Tube Nut
12 A58625 Injection Orifice Elbow Ay.
13 A85742 Nipple, Hex
14 B58283-4 Long Air Duct Ay.
15 B32145 Cleanout Brush Ay.
16 A85574 Carry Strap Ay.
17 B86226 Strap Pad
18 A58520 Kit, ¼ Turn Fastener (
Includes Stud, Washer & Receptacle)
Not Shown 58269-1 Engine/Antechamber Ay.
Not Shown 58250 Cleanout brush, antechamber
Not Shown 58590 Side Panel Bat. Side
35
