SPECIFICATIONS
Type…………………………………………..Thermal aerosol fog, resonant pulse principle
Formulation Output .....................0-9 Gal/Hr. ........................0-34 liters/hr.
Engine Performance ........................ 30 HP .... .22KW .....18,900 Kcal/hr.
Fuel Consumption .........................0.5 GPH ..........................1.9 Liters/hr.
Weight (Empty) ............................... 19 Lbs. ................................. 8.6 Kg
Weight (Filled) ................................. 27 Lbs. ............................... 12.2 Kg
Fuel Tank ..................................... 0.85 Qts. .............................. .8 Liters
Formulation Tank .............................. 1 Gal. ..............................3.8 Liters
Power Supply .................................................................8) 1.5V "D" size alkaline batteries
Length ................................................ 52 In. ................................ 132 Cm
Width ................................................. 9.5 In. ............................... 24.1 Cm
Height .............................................. 14.5 In. ............................... 36.8 Cm
Fog Particle Size ................................................……………………………..0.5-50 Microns
Shipping Data:
L x W x H ..................... 55 x 11 x 15.5 (In.) ....... 139.7 x 27.9 x 39.3 (Cm)
Weight........................................... 30 Lbs. ................................. 13.6 Kg
Cube ...................................... 5.43 Cu. Ft. ............................. 0.15 Cu.M.
TO THE NEW OWNER
This machine is one of the world's finest insecticide fog generators, built to precision standards. With
reasonable care and maintenance, this efficient mechanism will provide many hours of service. For best
results, this fog generator must be operated and maintained in compliance with these instructions.
CORRESPONDENCE
In all correspondence concerning the customer's machine and in ordering parts, the customer must
refer to the model and serial numbers of his machine. This information is found on the nameplate
attached to the machine.
DESCRIPTION
This fog generator employs the resonant pulse principle to generate hot gases flowing at high
velocity. The high velocity gases atomize the formulation instantly so that it is vaporized and condensed
rapidly causing negligible formulation breakdown. The fog particle size is readily controllable from
approximately 0.5 to 50 microns and greater. The smaller particle sizes correspond to the lower
formulation flow rates and the larger particle sizes correspond to the higher formulation flow rates. This
machine is intended for outdoor use and for enclosed spaces with volumes of more than 500 cubic feet
(14 cubic meters). Use in more confined spaces may create a fire or explosion hazard
.
WORKING PRINCIPLE
The engine is essentially a tube with a combustion chamber, an intake valve, and a supply of a
combustible mixture of fuel and air. To begin, a negative pressure is created in the fuel tank by
depressing a flexible priming bulb. This draws fuel into the priming bulb, which is then forced into the
antechamber and combustion chamber, where it is ignited by the spark plug. An explosion occurs in the
combustion chamber driving the gases out the engine tube. The negative pressure created by the gas
flow out the engine tube causes the intake valves to open allowing more air to pass through the venturi of
the carburetor. The air passing through the carburetor aspirates fuel from the carburetor in a combustible
mixture. This mixture is ignited again and the cycle is repeated. The frequency of repeated explosions is
many times per secon
d.
