Golden Eagle 3 Series - Tank-Side View of Machine

TANK-SIDE VIEW OF MACHINE
REF. CURTIS
NO. PART NO. DESCRIPTION
FIGURE 16
1 58522 Formulation Tank Ay.
C58522 Formulation Tank
A10105 Standpipe Connector
A58523 Formulation Standpipe
A85748 Elbow,ǩ MPT -¼T
G195463 Nut, ¼ Tube
G114628 Sleeve, ¼ Tube
A21120 Union Elbow
A21081-1 Plug, ǩ NPT-Male
2 N58565 Line Ay., Formulation Tank/Check Valve
A58212-3 Tube
A58239 Insert, Brass ¼ Tube
G145463 Nut,¼ Tube
G114628 Sleeve,¼ Tube
A743123-3 Spring, Anticrimp
3 N58564 Line Ay., Formulation Tank/Metering Valve
A58212-4 Tube
A58239 Insert, Brass ¼ Tube
G145463 Nut, ¼ Tube
G114628 Sleeve, ¼ Tube
4 C58254 Fuel Tank and Barb Ay.
5 N58608 Fuel Line Ay.
B80447-5 Tube, Vinyl, .312 Gres
A62017-1 Tube Guard
B80447-19 Tube, Vinyl, .312 Gres
A62017-2 Tube Guard
A58316 Filter, 3/16 x 75 Micro
A80296-3 Clamp, Hose, AL .301
A80296-4 Clamp, Hose BLK .321
6 N58605 Line Ay., Check Valve/Tee
A58212-1 Tube
A58239 Insert, Brass ¼ Tube
G145463 Nut, ¼ Tube
G114628 Sleeve, ¼ Tube
7 A58609 Switch, N.O., Rocker
8 N58615 Screw, 6-32 x ½ CRPH
9 A58534 Primer Blub Ay.
A63428 Primer Blub
A58601-1 Tube, Vinyl (6.5” long)
A58601-2 Tube, Vinyl (6.0” long)
10 B58272-4 Control Knob Ay.
