TOP COVER/HANDLE AY.
P/N 58539
REF. CURTIS
NO. PART NO. DESCRIPTION
FIGURE 11
1 B58546 Handle Grip
2 A58545 Actuator Knob
3 B58559 Control Knob Assy.
4 G140853 Set Screw, 8-32 x .375 (included in Knob Assy.)
5 B10100-112 ‘O’ Ring
6 A20200 Washer .53 ID x .75 OD
7 A32692 Packing Nut
8 A58612 Valve Locating Plate
9 B58548 Linkage Ay.
10 N58615 Screw, 6-32 x .5 CRPH
11 A58553 Trigger Rod
12 D58528 Handle Base
13 G120392 Washer, Flat, ¼, Regular
14 G121753 Washer, Lock ¼, External Tooth
15 G120854 Bolt, ¼-20 Hex
16 G140853 Screw, 8-32 x .375 Set
17 A58551 Handle End Closure
18 A20414 Internal hair Pin
19 G9419454 Nut, Lock ¼-20, Hex
20 A32524-1 Rubber Grommet
21 C58599 Reinforcing Plate
22 D58552 Top cover
23 B58561 Bracket, Formulation Valve
24 A32851-1 Lever and Stop Ay., Valve
25 G120382 Washer, Lock, Ǫ, Split
26 B32536-1 Valve Ay., Shutoff (see fig. 12, page 38)
27 G441789 Elbow, ǩ FP - ¼ T
28 A32670 Nut, Ǫ -24, Brass
29 A85748 Elbow, 90, ǩ MPT - ¼ T
30 B32693 Metering Value Body (see Fig. 13, Page 38)
31 A10040 Eyelet
32 453120 Screw, #10-24 x ¼
33 121801 Lockwasher #10
37
To Next Page
