VIII. BATTERY CHARGING
CHARGING THE BATTERIES
Your LiteRider PTC’s charging system is designed for your safety and for your convenience.
Follow the steps below to recharge the batteries.
1. Position your LiteRider PTC close to a standard wall electrical outlet.
2. Turn off the power on the joystick.
3. Insert the matching charger plug into the joystick’s charging socket that is located at
the front of the joystick or alternatively into the battery pack. See figures 18 and 19.



4. Insert the plug at the other end of the charger power cord into a standard electrical
wall outlet. (Power to the charger indicated by a red LED).
Note: Make sure the standard electrical wall outlet is not controlled by a light switch
causing the charger to accidentally shut off when it is activated.
5. Disconnect the charger power cord from the wall outlet and from the joystick
charging socket when the batteries are fully charged.
Note: The batteries should be fully charged in eight hours. A full charge is indicated, when
the charge LED turns green and all 10 joystick LEDs are lit when the joystick is turned on.
Alternatively, you may charge the battery pack directly.
1. Remove the battery pack from the power chair.
2. Locate the charger port on the side of the battery pack and swing the cover open.
3. Plug the charger into the battery pack socket.
4. Insert the plug at the other end of the charger power cord into a standard electrical
wall outlet.
5. Disconnect the charger power cord from the wall outlet and from the battery pack
charging socket when the batteries are fully charged.
30
Figure 18 Figure 1
9
Standard
Wall Outlet
*Alternate Char
g
in
g
Method
