GOLDONI 3070V - POWER RATINGS AND WEIGHTS

86
7.2 EXTERNAL WHEEL WIDTH
EXTERNAL WHEEL WIDTH
(The values are indicative - mm)
Wheel Width
6.5/80x1 5 - 9.5R24
Front: 1081-1341
Rear: 1003-1379
7.00x12 - 12.4R20
Front: 1100-1376
Rear: 1105-1417
8.0/75x15 - 11.2R24
Front: 1043-1447
Rear: 1050-1422
11.00/65x12 - 12.4R20
Front. 1267-1347
Rear: 1105-1417
11.00/65x12 - 360170x20
Front: 1267-1347
Rear: 1142-1454
7.3 POWER RATINGS AND WEIGHTS
The values are approximate and refer to the tractor without ballast, with the
driver, 12.4x20 wheels and roll bar.
Model
Description 3070StarV
2070V
WEIGHTS
Front axle (Kg) 800
Rear axle (Kg) 980
POWER
At the power take-off (kW) 42
Maximum towable weight (trailer with brake) Kg. 4270
Maximum towable weight (trailer without brake) Kg. 1020
Maximum vertical load on tow hook Kg. 680
POWER LIFT
Maximum travel at the end of the links (mm) 621
Maximum load at the end of the links (Kg) 1800
