2. INSTALLATION INSTRUCTIONS
3. All equipment must be sitting level for proper operation and combustion
where plinth type installation is made, plinth height and front overhang
must be 50 mm minimum. Levelling can be made by the use of metal
shims. For griddles where adjustable legs are provided, levelling can be
made easily due to the threaded construction of the legs.
Licensed plumber should make connection to main gas line. Install a
hand shut-off valve in gas line to the appliance manifold.
OVERALL DIMENSIONS
MODEL WxDxH
TK24 610 x 800 x 330
TK30 740 x 690 x 330
TK36 915 x 800 x 330
TK45 1120 x 690 x 330
