IM067B2 – June 2010
10
6. TECHNICAL INSTRUCTIONS
GAS CONNECTION
Have a licensed gas fitter or your local Gas Authority connect the appliance.
It is recommended that a valve and union be installed close to the appliance for
disconnection in the event of service.
Check thoroughly for gas leaks before attempting to light the appliance.
Check that all burners are in position.
Peel off all protective plastic and remove any glue with a solvent.
IMPORTANT
READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE LIGHTING AND USE.
GAS INLET CONNECTION
19mm NB BSP from below the appliance, 60mm from the right hand side looking at the
front of the appliance as shown on Page 11.
Electrical connection is a two (2) metre Three (3) pin flexible lead as shown on Page 11.
As from 1
st
January 2005. The new AGA AS4563/AG300 codes states that all L.P.G.
appliance will be supplied with a separate regulator for each appliance.
