NEXA MODULAR G2+ AUDIO AND VIDEO DOOR ENTRY SYSTEM - BUILDING
WIRING DIAGRAMS
Audio door entry system with 8 risers of 16 apartments/ ART 1/G2+ terminals in "IN-OUT" without distributors Golmar .and d.c lock release
Only audio installation, configure the end of line Dip 10 a OFF
in all audio terminals.
BUILDING 1
To "Bus M" of the FA-G2+ power supply (see page )49 .
Note: If more than 1 access door panel (see page 50-51).
A B C
80m 50m 45m
Cable
B+C
95m
D
15m
RAP-GTWIN/HF 2x1mm
2
Distances and cross-sections:
A
B
D
ART /G2+1
FA-G2+
ART /G2+1
Electrical junction box.
C
Riser 1 Riser 2
ART /G2+1
ART /G2+1
Note: IN-OUT installation with 8 risers without distributors,
max. 16 ART1/G2+ terminals per riser & 128 ART1/G2+
terminals per installation (building).
ART 1/G2+
Master
AUX
APARTMENT 1
( )2
ON
1 2 3 4 5 6 7
8 9 10
RISER 2RISER 1
*
( )
ART 1/G2+
Master
AUX
APARTMENT 2
( )2
ON
1 2 3 4 5 6 7
8 9 10
*
( )
ART 1/G2+
Master
AUX
APARTMENT 16
( )2
ON
1 2 3 4 5 6 7
8 9 10
*
( )
BUS
BUS
BUS
ART 1/G2+
Master
AUX
ART 1/G2+
Master
AUX
ART 1/G2+
Master
AUX
APARTMENT 17
APARTMENT 18
APARTMENT 32
AS RISER 1
BUS
BUS
BUS
RISER 3 , 4 & 5 AS RISER 1 RISER 6 , 7 & 8 AS RISER 1
RISER 3 RISER 4 RISER 5 RISER 6 RISER 7 RISER 8
Make the connections in
electrical junction box.
Riser 3
Riser 4
Riser 7
Riser 8
Riser 5
Riser 6
AUX
AUX
AUX
AUX
C
B: must be to 50m.
Important:
*
( )
(1)
For more information of the ART G2+ , see the1/ audio terminal quick guide that is attached with its corresponding product.
