golmar T-ART/G2+ User Manual

TELEPHONE DESCRIPTION:
4
Funtion push button:
Descrip i n:t o
- During call door panel, guard or intercom process: Led will blink (white color).
telephone in communication: Led switch on (white color).
- : Led switch on (red color)."Do not disturb" mode
Call forwarding process (with ART 7W monitor): Led blink (red color).
"Default tones & tones volume": Led blink 9 times (red color).
- Led switch on (red color)."Doctor mode":
HZ: ( )Black
Funtion status LED:
Descrip terminals:tion connection
During the call or communication processes: one press
will activate the lock release 2. In standby (handset on
the hook): press the button for 3 sec. to activate the
staircase light the 2+ & modules( SAR-G SAR-12/24
required 5 short press to default tones & tones).
volume (led blink 9 times). In standby (handset off
the hook): 2 short press to “intercom” call (within the
same apartment) and press for 3 seconds to
“autoswitch-on” function. See pages 9-10.
In standby : short press, it allows to(handset on the hook)
change tone call volume, on every short press
telephone reproduces the selected volume (cyclic min/
med/ max/ off "do not disturb"). pressIn call forwarding:
for more than 3 sec., to cancel the call transfer (with
ART 7W monitor). on every shortIn communication:
press, it allows to change the speaker of the T-ART
audio volume (cyclic 4 audio levels). See p. 9-10.
HZ: ( ed)R
GND: (Black)
SA: ( ed)R
During the call or communication processes: one
press will activate the lock release . In standby1
(handset on or off the hook): press the button for 5
seconds to activate/deactivate the "Doctor mode"
function. See page 9-10.
BUS, BUS: Communication BUS (non-polarised).
SA, GND:Auxiliary call repeater output (max 50mA/12V ), relay SAR-12/24.dc
HZ, HZ: Apartment front door button input:
Connect only on the master monitor. The signal received is then transmitted
to the slave monitors in the same apartment through the BUS.
Note: HZ push button function mode: When HZ push button is pressed will be call tone and activate the output of
auxiliary call repeater with standby telephone, call process, communication process (HZ tone with lower audio
level), intercom process and "Do not disturb" mode. Important: Up to 8 telephones/ apartments with push button
"HZ" activated at the same time (with system and telephones in standby).
BUS
BUS
T-ART/G2+ TELEPHONE
a.
b.
c.
d.
Handset.
Function push buttons.
Raised dots for the visually impaired people.
In call :/ com unicam tion
Above these raised dots is the "Door opening"
button.
Status Leds.
Wall mounting connector fixing (x4).
Gol,ar use.
Configuration switches.
Bus connection terminals.
Label.
Apartment front door button input .
"HZ"
Auxiliary call repeater output (máx 50mA/12V ).. dc
e.
f.
g.
h.
i.
j.
k.
b
a
d
e
i
k
h
g
f
c
AUX
DIP 8,9
00 - Master
10 - Slave 1
OFF = 0 | ON = 1
01 - Slave 2
11 - Slave 3
DIP 1 to 7
Monitor address
DIP 10
End of line resistor
BUS HZ
GND
GOLMAR S.A. C/ Silici, 13. 08940-SPAIN
SA
e
j
In standby (handset off the hook): one short press for
guard monitor calls (if exist). See pages 9-10.
