CHARACTERISTICS
- Monitor for Plus / Uno installation.
- 4.3” TFT colour screen.
- Monitor with 3 common wires plus coaxial cable.
- Monitor with 4 common wires plus twisted pair.
- Monitor with UTP cabling plus RJ-45 connector.
- Enables communication with hearing aids equipped with T-mode, making conversation possible (inductive loop).
- Function and advanced programming buttons (to customise the monitor's functions).
- Completely private conversation and image.
- Auto switch-on function.
- Auto spy function without occupying a channel.
- 'Doctor mode' function (automatic door opening, see p. 12).
- Intercom between two devices in the same apartment.
- Input for calls from the apartment front door.
- Call volume control (maximum, no volume 'night mode,' medium and minimum. See p. 5).
- Input for outside door release button.
- Output to auxiliary call repeater.
- Call to primary and secondary guard unit.
- Panic call to guard units.
- Different ringtones to identify call origin: Door panel, guard unit, intercom and interior door of the apartment.
- Activation of two auxiliary functions: second camera, courtesy lights, etc.
- Control of brightness and colour.
- DIP switches for setting the monitor address, 'call code' and master/slave (quick programming mode).
- Door release button.
- Monitor status LED.
- Programming LED.
SYSTEM OPERATION
3
- To make a call, the visitor presses the button for the apartment, a number of audible tones indicate that the call is being
made and LED on the door panel illuminates. At this moment, the apartment's monitor (telephone) receives the
call. If the visitor presses the button for another apartment by mistake, the call can be cancelled by pressing the button
for the correct apartment.
- In systems with several access doors, the other door panel(s) automatically disconnects; if another visitor attempts to
call, a number of telephone tones will indicate that the channel is busy and LED on the door panel will illuminate.
- General panels (EL501 mode): If the call is being made from the general entrance door panel, the interior door panel
of the building being called and other possible general entrance door panels automatically disconnect. If another
visitor attempts to call from either a busy interior door panel, a number of telephone tones will indicate that the channel
is busy and LED of the door panel will illuminate, or from another general entrance door panel, a number of
telephone tones will indicate that the channel is busy and LED of the general entrance door panel will blink for 3
seconds. The door panels of the other interior buildings will remain free to be used.
- General panels (EL501 mode): If the call is made from an interior panel, the other interior panels will remain free to be
used. It is only possible to make calls to interior buildings from the general entrance door panels when their door
panels are not in use. If an attempt is made to make a call to a busy interior door panel, a number of telephone tones
will indicate that the channel is busy and LED of the general entrance door panel will blink for 3 seconds.
- The call lasts for 45 seconds, during which time an image appears on the apartment's monitors for 2 seconds after the
call is received without the visitor knowing, and the status LED on the master monitor will illuminate (green). If the call
is not answered within 45 seconds, the master monitor's status LED will illuminate (red), LED on the door panel will
turn off and the channel will become free.
- To establish communication, lift the handset of the monitor, and the monitor's status LED (green) and the door panel's
LED will illuminate. The handset enables communication with hearing aidsCommunication with hearing aid :
equipped with T-mode, making conversation possible (inductive loop).
- Communication will last for one and a half minutes or until the handset is hung up. After communication, the monitor's
status LED will illuminate (red), the door panel's LED will turn off and the channel will be free.
- To open the door, press the door release button during the call or communication processes: one press will activate
the door release for 3 seconds and LED on the door panel will also illuminate for 3 seconds.
- Adescription of the function buttons can be found on p. 5.
TEKNA-S PLUS MONITOR
