golmar V2PLUS User Manual

Insert a 120 ohm end of
line resistor in the last
distributor.
*
D3
End of
line
BUSD2D1 BUS D4
BUS IN
PA PB
BUS OUT
HZ
*
R.1 20W
D4L-V2Plus
INSTALLATION DIAGRAMS
103
BUS IN
PA PB
BUS OUT
HZ
BUS IN
PA PB
BUS OUT
HZ
Platea V2Plus
Sw2
BUS IN
PA PB
BUS OUT
HZ
Platea V2Plus
Sw2
Configuring the end of
line in the last monitor.
Platea V2Plus
Sw2
BUS IN
PA PB
BUS OUT
HZ
Platea V2Plus
Sw2
BUS IN
PA PB
BUS OUT
HZ
Platea V2Plus
Sw2
Platea V2Plus
Sw2
aisy chain installation for a video door entry system with a 4 line distributor and d.c lock release
D
.
The installation diagram shows the connection of a video door entry system with one door
panel to access the building, two riser and one distributor of 4 line with a
daisy chain installation and d.c. lock release
D4L-V2Plus
.
REMEMBER:
.
In a daisy chain installation with distributor, the total number of elements
(monitors or telephones) distributed over all 4 outputs of the distributor must never exceed
32 units, while one single output must never exceed 16 units
104
Master door panel
BUS
CV1
+12
CV2
SW1
6
SEC
PRI
+
0110230
FA-V2PLUS
- -
+
Main
Sections chart
RAP-2150
Terminal
SECTIONS CHART
100m.
Door panel-Monitor
P.S. - Door panel
+, -
For greater distances contact our technical
support department.
BUS, D
50m.
Door panel - CV
50m.
2,5mm²
0,5mm²
CV1,CV2
IMPORTANT: In the output to the monitor/telephone of a
.
distributor cannot be connected
another distributor
**
****
