User‘s Manual
22
M6x12 M-C 3
Adjusable part
M-E 3
Snap ring M6
M-F 3
Adjustable part
M-G 2
Spacer
M-H 6
Tools
Allen wrench
4mm
M-D 1
Tab. 14: Scope of Delivery
2.2 Required Tools
Tool Figure
Line tester
Pencil
Drilling mashine
Concrete drill 8x60mm
Phillips head screwdriver
Second person
Tab. 15: Required Tools
