4.4 Installing the mounting legs
Risk of material damage by improper
procedure
>> Only use moderate force when tightening
the screws in order to avoid damaging
threads.
Tab. 19: Installing the mounting legs
Phillips head screwdriver
4.4.1 ON TOP Version (General)
1. Install the 3 mounting legs (D)
as shown either
>> with the screws (M-B) and
the spacers (M-H) in
single version or
>> in double version
ding on the construction of
your beamer or projectior.
Tighten the screws in a way that the
mounting legs stay adjustable.
Fig. 23:
ON TOP Version (General)
