Goodman GMP - Horizontal Installation; Downflow Installation

IO137 22
DOWNFLOW INSTALLATION
VENT
RETURN
SUPPLY
SUPPORT OR SUSPEND
UNIT IN THREEE PLACES:
LEFT, RIGHT, AND CENTER.
HORIZONTAL INSTALLATION
RETURN
A
IR
VENT
PIPE
SUPPLY AIR
MAINTAIN
PROPER
CLEARANCES TO
COMBUSTIBLES
OPTIONAL NON-COMBUSTIBLE
SUB BASE (SBM-XXX) NECESSARY
WHEN INSTALLED ON
COMBUSTIBLE FLOORING
WITHOUT COOLING COIL
