CONDENSING UNIT SPECIFICATIONS
7
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance
with all national and/or local electrical codes. Use copper wire only.
GSX130[18-60]1B*
(1)
Wire size should be determined in acordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use time delay fuses or HACR-type Circuit Breakers of the same size as noted.
NOTES:
* Always check the S&R plate for electrical data on the unit being installed.
* Installer will need to supply 7/8" to 1 1/8" adapters for suction line connections.
* Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
* Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED
BY THE OUTDOOR UNIT NOT THE INDOOR COIL.
* Line sizes denoted for less than 25' line sets, tested and rated in accordance with AHRI Standard 210/240. For other line-set lengths or sizes, refer to
the Installation and Operating Instructions and/or the long line-set guidelines.
GSX130181B* GSX130241B* GSX130301B* GSX130361B*
Cooling Capacity, BTUH 18,000 24,000 30,000 36,000
Compressor
R.L. Amps 9.00 13.5 12.8 16.7
L.R. Amps 48.0 58.3 64.0 79.0
High Pressure Switch
Open N/A N/A N/A N/A
Close N/A N/A N/A N/A
Condenser Fan Motor
Horsepower 1/6 1/6 1/6 1/6
F.L. Amps 1.10 1.10 1.10 1.10
Liquid Line, Inches O.D.* 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D.* 3/4" 3/4" 3/4" 3/4"
Refrigerant Charge 72.0 79.0 81.0 95.0
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
12.3 18.0 17.1 21.9
Maximum Overcurrent Device
(2)
20 30 30 35
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight
149 151 152 159
GSX130421B* GSX130481B* GSX130601B*
Cooling Capacity, BTUH 42,000 48,000 60,000
Compressor
R.L. Amps
17.9 19.9 25.0
L.R. Amps 112.0 109.0 134.0
High Pressure Switch
Open N/A N/A N/A
Close N/A N/A N/A
Condenser Fan Motor
Horsepower 1/4 1/4 1/4
F.L. Amps 1.50 1.50 1.50
Liquid Line, Inches O.D.* 3/8" 3/8" 3/8"
Suction Line, Inches O.D.* 7/8" 7/8" 1 1/8"
Refrigerant Charge
90.0 104.0 125.0
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
23.9 26.3 26.3
Maximum Overcurrent Device
(2)
40 45 45
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight
194 195 200
