CONDENSING UNIT SPECIFICATIONS
8
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance
with all national and/or local electrical codes. Use copper wire only.
GSX130181C*
GSX130181C*
Cooling Capacity, BTUH 18,000
SEER/EER 13 / 11
Compressor
R.L. Amps 6.70
L.R. Amps 40.0
High Pressure Switch
Open N/A
Close N/A
Condenser Fan Motor
Horsepower 1/6
F.L. Amps 1.10
Liquid Line, Inches O.D.* 3/8"
Suction Line, Inches O.D.* 3/4"
Refrigerant Charge 71.0
Power Supply 208/230-60-1
Minimum Circuit Ampacity
(1)
9.5
Maximum Overcurrent Device
(2)
15
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4
Approximate Shipping Weight
135
(1)
Wire size should be determined in acordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use time delay fuses or HACR-type Circuit Breakers of the same size as noted.
NOTES:
* Always check the S&R plate for electrical data on the unit being installed.
* Installer will need to supply 7/8" to 1 1/8" adapters for suction line connections.
* Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
* Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED
BY THE OUTDOOR UNIT NOT THE INDOOR COIL.
* Line sizes denoted for less than 25' line sets, tested and rated in accordance with AHRI Standard 210/240. For other line-set lengths or sizes, refer to
the Installation and Operating Instructions and/or the long line-set guidelines.
