CONDENSING UNIT SPECIFICATIONS
9
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in accordance
with all national and/or local electrical codes. Use copper wire only.
GSX130[18-36]1D*
GSX130181E*
(1)
Wire size should be determined in acordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use time delay fuses or HACR-type Circuit Breakers of the same size as noted.
NOTES:
* Always check the S&R plate for electrical data on the unit being installed.
* Installer will need to supply 7/8" to 1 1/8" adapters for suction line connections.
* Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
* Installation of these units requires the specified TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED
BY THE OUTDOOR UNIT NOT THE INDOOR COIL.
* Line sizes denoted for less than 25' line sets, tested and rated in accordance with AHRI Standard 210/240. For other line-set lengths or sizes, refer to
the Installation and Operating Instructions and/or the long line-set guidelines.
GSX130181E*
Nominal Cooling Capacity, BTUH 17,800
SEER/EER 13 / 11
Compressor
R.L. Amps 6.70
L.R. Amps 41.0
High Pressure Switch
Open N/A
Close YES
Condenser Fan Motor
Horsepower 1/8
F.L. Amps 0.70
Liquid Line, Inches O.D.* 3/8"
Suction Line, Inches O.D.* 3/4"
Refrigerant Charge 73.0
Power Supply 208/230-60-1
Minimum Circuit Ampacity
(1)
9.1
Maximum Overcurrent Device
(2 )
15
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4
Approximate Shipping Weight
120
GSX130181D* GSX130241D* GSX130301D* GSX130361D*
Nominal Cooling Capacity, BTUH 18,000 24,000 30,000 36,000
SEER/EER 13 / 11 13 / 11 13 / 11 13 / 11
Compressor
R.L. Amps 6.70 13.5 12.80 14.1
L.R. Amps 40.0 58.3 64.0 77.0
High Pressure Switch
Open N/A N/A N/A N/A
Close N/A N/A N/A N/A
Condenser Fan Motor
Horsepower 1/8 1/8 1/8 1/4
F.L. Amps 0.70 0.70 0.70 1.50
Liquid Line, Inches O.D.* 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D.* 3/4" 3/4" 3/4" 7/8"
Refrigerant Charge 70.0 76.0 76.0 77.0
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
9.1 17.6 16.7 19.1
Maximum Overcurrent Device
(2)
15 30 25 30
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight
120 130 130 140
