Page 6
Unit Specifications and Features
1
Unit
Specifications
and Features
NOTE:
A guide on using the infrared remote is not included in this literature package.
Unit Parts
“ ” for 3 seconds when:
• TIMER ON is set
• FRESH, SWING, TURBO, SILENCE or SOLAR PV ECO features are turned on
“ ” for 3 seconds when:
• TIMER OFF is set
• FRESH, SWING, TURBO, SILENCE or SOLAR PV ECO features are turned off
“ ” when defrosting
“ ” when anti-cold air feature is turned on
“ ” when unit is self-cleaning
“ ” when freeze protection is turned on
Display Code
Meanings
In Fan mode, the unit will display the room temperature.
In other modes, the unit will display your temperature setting.
,
,
“ ”
When ECO function(optional) is activated, the
illuminates gradually one by one as --
-- --set temperature-- ...... in one second interval.
Power Cable (Some Units
)
Remote Control
Remote control Holder
(Some Units)
Functional Filter
(On Front of Main Filter - Some Units)
Louver
Front Panel
Display window
Display window
(1)
(2)
“ ” when wireless Control feature is activated(some units)
To Next Page
