Goodman R-410A User Manual

47
WIRING DIAGRAMS
HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
GPH13MED ECONOMIZER FOR *PH15**M4*
*PH15**M4*
YELLOW
WHITE
W
GOODMAN MANUFACTURING CO. MODEL GPH13MED ECONOMIZER
ROOFTOP UNITS
GPC & GPH SERIES WIRING DIAGRAM
NOTE: RECOMMEND MULTI-STAGE T'STAT
B
ORANGE
*PH SERIES WIRING DIAGRAM
