Front View
Rear View
Side View
2.2
2.3
2.3
LED indicator
Shows the source type by different
colours.
A
A
B
C
D
E
F
F
G
G
H
AC power input
Used to connect Base to the mains
power supply.
Optical digital input
Connect to television’s opitical digital
output.
Coaxial digital input
Connect to television’s coaxial digital
output.
Aux in stereo input
Connect external audio sources with
a 3.5mm audio cable.
Line in stereo input
Connect to your television’s analogue
stereo output.
button
Press to turn Base on/off.
button
Press to change the input source.
button
Press to increase the volume.
button
Press to decrease the volume.
I
J
B
C
D E
H I J
To Next Page
