7.2 MPD Series Technical Parameters
Technical Data MPD200-40-US10 MPD200-63-US10
Electrical Data
Nominal Output Voltage (V) 240
Output Voltage Range (V) 211~264
Feed-in Type Split Phase
Nominal AC Voltage of Line Conductor (V) 120/240
Nominal AC Frequency (Hz) 60
AC Frequency Range (Hz) 58.5~61.2
Current Rating (From Grid)(A) 200
Max. Continuous Current From Inverter (A) 32 47.5
Max. Amount of Inverters in Parallel 3
Maximum Overcurrent Protection of Main
Breaker (A)
*1
200
Maximum Overcurrent Protection of Circuit
Breaker of Inverter (A)
40 63
General Data
Operating Temperature Range (℉) -13℉~+140℉ (-25℃~+60℃)
*2
Max. Operating Altitude (ft) 9842ft (3000m)
Cooling Method Natural Convection
Communication with Inverter RS485
Weight (lb) 30lb (13.5kg)
Dimension (W×H×D in) 17.7×24×5.9 in (450×610×150 mm)
Mounting Method Wall Mounted
Ingress Protection Rating Type 3R, IP44
Certication
Safety Regulation UL1741, CSA 22.2 No. 107-01
EMC FCC part15 CLASS B
*1: The main breaker is optional.
*2: Derating temperatrure: 113℉(45℃).
